ipdc2000 series dc feedback electronic load adopts three-phase pfc feedback design, pure digital pwm rectification technology, high power factor, low pollution to the grid, high output accuracy, fast dynamic response, and 100% energy feedback to the grid; built-in bms battery management system simulation function, external national standard charging gun holder; power access and output interface, with electrical safety protection function, thd and injected harmonic current meet the national standard gb/t 14549-93; also meet gb/t18488.1-2015, gb/t18488.2-2015, gb/t29307-2012 test items in the use of power requirements; can also be used for new energy electric vehicle dc charging pile testing and aging。
|
gb/t 18487.1-2015
|
electric vehicle conductive charging system part 1: general requirements
|
|
gb/t 27930-2015
|
the communication protocol between the electric vehicle off-board conductive charger and the battery management system
|
|
gb/t20234.1-2015
|
connecting devices for conductive charging of electric vehicles part 1: general requirements
|
|
gb/t20234.3-2015
|
connecting devices for conductive charging of electric vehicles part 3: dc charging interface
|
|
nb/t 33001-2010
|
technical requirements for off-board conductive chargers for electric vehicles
|
|
nb/t33008.1-2013
|
specification for inspection and test of electric vehicle charging equipment part 1: off-board chargers
|
◆ three-phase p.f.c feedback design, using dc/dc bidirectional conversion two-stage circuit, electrical isolation。
◆ 100% energy feedback, low feeder current pollution, high input power factor: >0.99, harmonics <3% during rated operation。
◆ intelligent monitoring function, friendly man-machine interface, remote control via can bus or pc。
◆ with constant voltage (cv) and constant current (cc) operation modes。
◆ built-in bms battery management system simulation function, external national standard charging gun holder。
◆ save 75% of aging electricity, reduce 80% of aging heat, and reduce 50% of equipment main power configuration。
◆ the self-checking function of the equipment at power-on can automatically detect whether the working status of the instrument is normal or not, ensuring the safety of the testing process。
◆ discharge current, discharge time, discharge capacity and other setting functions。
◆ with multiple safety automatic protection functions, such as short circuit, over current, overload, over temperature and other automatic protections, to ensure the safety and stability of the instrument during long-term high-current discharge。
◆ adopting two-way pwm rectification technology, which can directly return the power supply energy to the grid, with a feedback efficiency of over 85%。
◆ power access and output interface, with electrical safety protection function。
◆ with rs232 rs485 can and ethernet ports。
◆ the voltage and current can be customized according to customer needs。
|
ipdc2000 series dc feedback electronic load
|
|
model number
|
ipdc2050
|
ipdc2100
|
ipdc2150
|
ipdc2200
|
ipdc2300
|
ipdc2500
|
|
capacity
|
50kw
|
100kw
|
150kw
|
200kw
|
300kw
|
500kw
|
|
accharacteristics
|
number of phases
|
3ф4 pe three-phase four-wire ground wire
|
|
voltage
|
380v±15%
|
|
frequency
|
47hz-63hz
|
|
power factor
|
≥0.99 (rated power)
|
|
current harmonics
|
≤3% (rated power); high-quality discharge energy 100% feedback to the grid, high efficiency and energy saving, no pollution to the grid.
|
|
power mode
|
|
output
|
voltage
|
current
|
|
0-500v
|
±0-150a
|
±0-300a
|
±0-450a
|
/
|
/
|
/
|
|
0-800v
|
±0-90a
|
±0-180a
|
±0-270a
|
±0-360a
|
±0-540a
|
±0-900a
|
|
0-1200v
|
±0-60a
|
±0-120a
|
±0-180a
|
±0-240a
|
±0-360a
|
±0-600a
|
|
load pattern
|
|
constantvoltagemode
|
range
|
0-rated voltage
|
|
resolution
|
0.1v
|
|
setting/readback accuracy
|
≤0.1%fs
|
|
constant current mode
|
range
|
0-rated current
|
|
resolution
|
0.1a
|
|
setting/readback accuracy
|
≤0.1%fs
|
|
constant power mode
|
range
|
0-rated power
|
|
resolution
|
0.1kw
|
|
setting/readback accuracy
|
≤0.5%fs
|
|
constant resistance mode
|
range
|
1ω-1kω
|
|
resolution
|
0.01ω
|
|
setting/readbackaccuracy
|
≤0.1%fs
|
|
voltage ripple
|
0.2%fs (full scale)
|
|
current ripple
|
0.3%fs (full scale)
|
|
power regulation rate
|
±0.1%fs
|
|
load adjustment rate
|
±≤0.1%
|
|
time accuracy
|
setting 0.1sec 0.1%
|
|
voltage resolution
|
vo＜1000v:0.1v；vo≥1000v:1v
|
|
current resolution
|
output lo＜10a: resolution 0.001a; output 100＞lo≥10a: resolution 0.01a; output 1000＞lo≥100a:
|
|
communication interface
|
resolution 0.1a; output lo≥1000a: resolution 1a
|
|
current limit setting
|
rs 232c [ieee 488.2 (gpib) optional]
|
|
pressure limit setting
|
0-max current (power supply protection over current setting value, stop output)
|
|
protect
|
overvoltage, overcurrent, overtemperature, overload, short circuit
|
|
cooling method
|
fan 2 forced cooling
|
|
operating environment
|
0-40℃ (outdoor -20℃-50℃ needs to be customized) 20-90%rh
|
|
product size
|
50k-100k：w800*h890*l1000mm；120k-150k:w1000*h2000*l850mm
|
