the specification of 150v45kw-50kw resistor load equipment requires that the load equipment meets 150v/500a, and the power is 45kw and 8 gears are controlled and loaded independently.
specification requirements for 150v45kw-50kw resistance load equipment
specification requirements for 150v45kw-大发电子平台游戏官网
the load equipment meets the requirements of 150v/500a, and the power is 45kw and 8 gears are controlled and loaded independently.
2.1 devic.
1) independent control in 8 gears.
2) power 45~50kw.
3) voltage 150v.
4) current 500a.
5) resistive load.
2.2 appearance.
1) the famous brand logo is clear and easy to identify.
2) equipment safety warning signs are eye-catching and easy to see.
2.3 resistance parameters.
r mode reference:
|
|
r1
|
r2
|
r3
|
r4
|
r5
|
r6
|
r7
|
r8
|
|
power
|
10a
|
20a
|
20a
|
100a
|
100a
|
100a
|
100a
|
100a
|
|
resistance value
|
15
|
7.5
|
7.5
|
1.5
|
1.5
|
1.5
|
1.5
|
1.5
|
|
serial number
|
function
|
description
|
|
1
|
load display
|
in the loading state, there must be an indicator light or other indication of a resistance.
has been loaded.
|
|
2
|
voltage display
|
the load needs to have the function of voltage display.
|
|
3
|
current display
|
load displays the current load current
|
|
4
|
temperature display and control
|
displays the load temperature value and the temperature controls the start and stop of the cooling fan.
|
|
5
|
general control function
|
load requires total output control
|
|
6
|
alarm function
|
over-temperature acousto-optic alarm
|
|
7
|
protection
|
overtemperature protection function
|
|
8
|
fan fever
|
adopt the upper exhaust fan heat mode or the rear exhaust heat dissipation method.
|
